When using many universes this often provides a much better solution that using Art-Net in broadcast mode. Note that using both Unicast addresses doubles the amount of network traffic.ĪCN Streaming DMX (sACN) uses multicast to output DMX data onto the network. This additional broadcast can be inhibited by setting Setup, View Settings, Hardware, Reduced Rate DMX to "M+C no broadcast". Note that MagicQ will still broadcast that universe once per second - this allows all other consoles on the network to determine that there is a console outputting Art-Net for this universe.
When a Unicast address is manually set and the universe is set to Output Art-Net, MagicQ sends data for that universe direct to the unicast address rather than broadcasting that universe. The IP addresses of Art-Net compliant devices on the network can be viewed in Setup Window, View System, View Status, Art-Net nodes. Set the Unicast fields for each universe in DMX I/O. MagicQ can also be manually configured to unicast Art-Net to the IP addresses of two specific devices. MagicQ then automatically unicasts Art-Net to detected Art-Net nodes rather than broadcasting. Set the Art-Net type setting in Setup, View Settings, Network to "V4 unicast". When using Art-Net on a network with 32 or more universes it is recommended to use unicast Art-Net rather than broadcast Art-Net. MagicQ does not require any binding with nodes when using Art-Net in the default configuration. MagicQ will broadcast Art-Net over the network. To use Art-Net simply configure the Output Universe type to Art-Net, set the Out Uni field to the desired Art-Net universe and set the status for the universe to enabled. MagicQ Dual DMX modules, MagicDMX interfaces and SnakeSys Ethernet to DMX Interfaces use their own internal processor to ensure correct DMX framing at high DMX refresh rates.įor network protocols such as Art-Net and Pathport it is necessary to set up the Out Uni and In Uni fields - these determine which the ID of the Universe when carried over Ethernet.Ī ! by a Universe indicates a clash whereby more than one Universe is being output on the same network Universes.Īrt-Net™ Designed by and Copyright Artistic Licence Holdings Ltd.
#MULTITOUCH VISUALIZER 2 PRO#
Note Enttec Pro is not supported with MagicQ on Apple M1 Hardware. ChamSys are unable to offer support for these interfaces. *Legacy Devices no longer actively developed and supported.
#MULTITOUCH VISUALIZER 2 SOFTWARE#
On older versions of software whenever the MQ40N or MQ40 was first started or reset then it defaulted back to the simple settings - this was intentional to ensure that basic users saw the simple settings on start up and were not confused by all the advanced features.Īrt-Net 1,2,3,4 protocols (over Ethernet)ĭMX outputs from MagicQ Pro and Expert consolesĮnttec Pro dongle/Lumen Radio Nova wireless
#MULTITOUCH VISUALIZER 2 PATCH#
For more advanced features of MagicVis, and for patch features like Clone and Morph use Advanced Settings.įrom 1.8.0.2 on all MagicQ consoles the Advanced Setting option is saved and will appear on start up and reset as it was before the start up or reset. Items can be moved around in the Visualiser using the X, Y, Z encoders. When "Advanced Settings" is "Disabled" then the Patch Window shows a simplified view with one only one tab and simple buttons to CHOOSE HEAD and PATCH IT. More advanced users can access the advanced settings by setting the Advanced Settings = "Enabled" in Setup, View Settings, Mode.
The MQ40/MQ40N user interface has a reduced number of options to ensure that it is easy to use for users unfamiliar with lighting programs.
